Active Components has partnered with PDC (Prosperity Dielectrics Corporation) for many years, providing customers across Australia and New Zealand with access to a range of MLCCs and chip resistors for demanding electronic applications.
From high-capacitance and high-voltage capacitors to current-sensing and precision resistors, PDC offers component options across power, automotive, EV, energy and industrial applications.
MLCCs
PDC's MLCC range covers general-purpose, automotive, safety, high-voltage and specialised applications, with case sizes from 01005 to 2225 and dielectric options including NPO, X7R, X7S, X6S, X5R and Y5V.
Key options include:
- High-capacitance X7R: highlighted products up to 22µF
- High-voltage: 100V–4kV options, with NPO and X7R dielectrics
- Safety: X1/Y2 and X2 options with UL and TUV certification
- Automotive: AEC-Q200 options for EV BMS, on-board chargers, DC-DC converters and inverters
- High-temperature: X8L options operating from -55°C to +150°C
View range here: Click Here
Chip Resistors
PDC's chip resistor portfolio includes current-sensing, high-precision, high-power, anti-surge, anti-sulfur, high-voltage and automotive options.
Key options include:
- Current sensing: resistance from 0.5mΩ, with power ratings up to 3W and low-TCR options
- High precision: thin-film options from 5–50ppm TCR and 0.01–0.5% tolerance
- High power: high-power and triple-power options
- Protection: anti-surge and anti-sulfur options
- Automotive: AEC-Q200 options
These components are suited to applications including BMS, battery packs, power supplies, automotive, industrial equipment and power electronics.
View full PDC resistor range: Click Here
A Broader Solution for Demanding Applications
Together, PDC's MLCC and chip resistor ranges provide component options across power conversion, energy storage, EV and automotive electronics, industrial equipment and battery management systems. The combination of high-capacitance and high-voltage MLCCs with current-sensing, precision and high-power resistors allows engineers to select components based on the specific electrical and environmental requirements of their application.
For applications where factors such as voltage, capacitance, resistance, power rating, temperature or automotive qualification need to be carefully considered, the PDC range offers a variety of specifications and configurations to work from.
PDC Components Through Active Components
Whether you're developing a new design, looking for an alternative component or working to specific electrical requirements, the PDC range provides a range of options to consider.
With our longstanding partnership with PDC, Active Components can help you find the right component for your application and specifications.
Contact Us: Click Here
